Woodward 5437-687 Field Terminal Module

Functional Description

The 5437-687 is a NetCon 24 Channel FTM developed by Woodward. Field Termination Modules (FTMs) serve as pivotal components, establishing a seamless connection between field wiring and the front of MicroNet control's I/O Modules. They enhance the integration of various components within the control system, offering multiple benefits that improve convenience and operational efficiency.

The primary purpose of FTMs is to provide a reliable interface linking field wiring to the subminiature D-type connectors positioned on the front of the I/O Modules. This direct linkage ensures efficient data transmission and communication between field devices and the control system, facilitating critical information exchange for accurate monitoring and control.

Features

• Cage-Clamp Terminal Connection Points:

  • Provides a secure and efficient means of attaching field wiring to the I/O Modules.
  • The cage-clamp design ensures a dependable connection that remains stable in challenging environmental conditions, reducing signal loss and interference.

• Shield Termination and EMI Protection:

  • Minimizes the impact of external electromagnetic disturbances on signal integrity.
  • Integrating EMI protection helps maintain signal quality, ensuring accurate and reliable data exchange.

• Compatibility with 35 mm DIN Rails:

  • Allows for easy and standardized mounting, enhancing organization and structure within the control system.
  • Simplifies installation and maintenance processes, providing quick access for adjustments or replacements.

• Elimination of Interposing Terminal Blocks:

  • Streamlines the connection process by removing the intermediary step, reducing complexity and potential points of failure.
  • Enhances overall efficiency, reduces maintenance requirements, and optimizes space within the control panel.

Specifications

• Part Number: 5437-687
• Manufacturer: Woodward
• Function: Field Terminal Module
• Type: PLC Link Module
• Dimensions: 6.25 x 3.50 x 2.75 inches
• Number of Channels: 24
• Weight: 0.55 lbs
