Schneider 140ERT85410Z Multifunction Input Module

Description

The Schneider 140ERT85410Z is a multifunction input module designed for the Modicon Quantum automation platform. It is an upgraded version of the 140ERT85410 module, featuring enhanced diagnostic capabilities and CRC checks for improved reliability.

Features

• Multifunction Input Module: Supports multiple input types and functionalities.
• Status Logging: Capable of logging status and events with time and date stamps.
• Time Synchronization: Utilizes the DCF77 time synchronization protocol.
• Enhanced Diagnostics: Includes CRC checks for improved diagnostic capabilities.
• Compatibility: Compatible with Unity Quantum, not with Concept Quantum.

Technical Specifications

• Number of Terminals: 40
• Discrete Input Number: 32 (24…125 V process input)
• Switching Voltage: 125 V, 1 mA process input
• Maximum Power Consumption: 7.5 W
• Insulation: By optocoupler
• Anti Bounce Filtering: Configurable from 0 to 255 ms
• Acquisition Time: 1 ms
• Input Current: 5 mA clock signal input
• Electrical Connection: Shielded and unshielded cables
• Local Signalling: LEDs for communication, self-test, fault, and input status
• Current Consumption: 0.07 mA at 24 V DC
• Operating Temperature: 0…60 °C
• Storage Temperature: -40…85 °C
• Relative Humidity: 95% without condensation
• Operating Altitude: Up to 5000 m
• Protective Treatment: TC
• Certifications: CSA, UL, C-tick, GOST
