ICS Triplex T8403C Trusted Digital Input Module
Specifications
Manufacturer: Triconex
Product No.: T8403C
Condition: 10 Items in Stock
Product Type: Automation Control Components
Product Origin: USA
Payment:T/T, Western Union
Weight: 330g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
Overview
The ICS Triplex T8403C is a Triple Modular Redundant (TMR) Trusted Digital Input Module designed for safety-critical applications up to SIL 3 and PL e (Cat. 4). It is certified for use in accordance with CENELEC standards and offers a high level of fault tolerance and diagnostic capability.
Features
- Three 32-bit microprocessors for TMR architecture
- 40 digital input channels
- 24 VDC nominal operating voltage
- Onboard diagnostics and event sequence (SOE) reporting
- Open and short circuit detection
- Configurable voltage threshold for each channel
Technical specifications
- Input voltage range: 12 VDC to 30 VDC
- Input current: 2 mA per channel
- Output voltage range: 0 VDC to 24 VDC
- Output current: 100 mA per channel
- Response time: <10 ms
- Operating temperature: -40°C to +70°C
- Storage temperature: -40°C to +85°C
- Humidity: 5% to 95% RH (non-condensing)
- Vibration: 5 g RMS, 10 Hz to 500 Hz
- Shock: 30 g, 11 ms half-sine
- EMC: EN 61000-6-2, EN 61000-6-3
Contact US
Email: Pambo@5gplc.com
Tel:+86 13306036024 (Whats-app, Skype)
Welcome to consult our staff. We will give you the best service and price. Thank you
FAQ
Q: How long is your delivery time?
A: Generally it is 2-3 days if the goods are in stock. If the goods are not in stock, Need to negotiate.
Q: Are you a trading company or manufacturer?
A: We are a trading company.
