GE Fanuc HYDRAN M2-X Advanced Transformer Monitoring System

Product Description

GE HYDRAN M2-X is an advanced transformer monitoring system designed to ensure the optimal performance and longevity of transformers. It continuously monitors key parameters to detect potential issues early.


Technical Specifications

• Model Number: HYDRAN M2-X
• Measurement Parameters: Hydrogen, moisture, and temperature
• Hydrogen Measurement Range: 0 to 2000 ppm
• Moisture Measurement Range: 0 to 100% RH
• Temperature Measurement Range: -20°C to +120°C
• Power Supply: 90-264V AC, 47-63 Hz
• Communication Interfaces: RS485, Modbus, Ethernet
• Operating Temperature: -40°C to +60°C
• Dimensions: 280mm x 160mm x 140mm
• Weight: 3.2 kg
• Compliance: Meets international standards for transformer monitoring

Features

• Continuous Monitoring: Provides real-time monitoring of transformer health.
• Multi-Gas Detection: Detects hydrogen and moisture in transformer oil.
• Data Logging: Records and stores historical data for trend analysis.
• User-Friendly Interface: Features a simple interface for easy operation and configuration.
• Remote Monitoring: Supports remote data access and control via communication protocols.
