GE 760-P5-G5-S5-HI-A20R Feeder Management Relay Multilin

Overview

The GE 760-P5-G5-S5-HI-A20R is a microprocessor-based feeder management relay designed for the protection, control, and monitoring of electrical power distribution systems. It features a combination of a Motorola 68332 32-bit microprocessor and an Intel 80C186 16-bit microprocessor, providing fast and accurate processing of input and output signals.

Technical Specifications

• Current inputs: 5 A phase and zero sequence, 5 A sensitive ground
• Voltage inputs: 120/240 V AC or 110/220 V DC
• Power supply: 88-300 V DC or 70-265 V AC
• Communication ports: Ethernet, RS-232, RS-485
• Operating temperature: -40°C to +85°C
• Dimensions: 180 x 165 x 215 mm (W x H x D)

Features

• Comprehensive protection: The 760-P5-G5-S5-HI-A20R provides a wide range of protection functions for feeders, including overcurrent, phase, ground, and differential protection.
• Advanced metering: The relay provides accurate metering of all electrical parameters, including current, voltage, power, and energy.
• Flexible communications: The 760-P5-G5-S5-HI-A20R supports a variety of communication protocols, including Modbus, DNP3, and IEC 61850.
• User-friendly interface: The relay features a large backlit LCD display and a menu-driven interface that is easy to use.
• Rugged construction: The 760-P5-G5-S5-HI-A20R is designed to withstand the harsh environments of power substations.
