GE 750-P5-G1-S1-HI-A20-R Feeder Management Relay

Overview

The GE 750-P5-G1-S1-HI-A20-R is a feeder management relay that provides comprehensive protection for distribution feeders on solidly grounded, high impedance grounded, or resonant (Peterson Coil) grounded systems. It is a versatile relay that can be used in a wide range of applications,

Technical Specifications

• Input voltage range: 10-30 VDC
• Input current range: 0.5-5 A
• Output voltage range: 0-5 VDC
• Output current range: 0-100 mA
• Communication protocols: Modbus RTU, DNP3, IEC 61850
• Operating temperature range: -20°C to +70°C
• Storage temperature range: -40°C to +85°C

Features

• Comprehensive feeder protection: The 750-P5-G1-S1-HI-A20-R provides a wide range of protection features, including overcurrent, over/undervoltage, over/underfrequency, and phase reversal.
• High-speed fault detection: The 750-P5-G1-S1-HI-A20-R can detect faults in as little as 1 millisecond, which helps to minimize damage to equipment and reduce downtime.
• Flexible communication options: The 750-P5-G1-S1-HI-A20-R supports a variety of communication protocols, including Modbus RTU, DNP3, and IEC 61850. This makes it easy to integrate the relay into existing SCADA systems.
