EPRO CON041/SF+PR6423/015-111 Eddy Current Signal Converter In Stock Brand New

Overview
The EPRO CON041/SF+PR6423/015-111 Eddy Current Signal Converter is a non-contact system designed to monitor vibration in industrial machines. It combines an eddy current sensor and a signal converter for comprehensive functionality. The sensor uses eddy currents to measure the displacement of a target object, such as a shaft or bearing, relative to the sensor. This displacement data is then converted into a 4-20mA analog signal by the signal converter, which can be easily interfaced with control systems and monitoring equipment.

Technical Specifications

• Sensor Type: PR6423
• Measuring Range: 2.0mm (Standard Range)
• Linearity Error: ≤ 1.0%
• Output Signal: 4-20mA
• Supply Voltage Range: -23V to -32V
• Operating Temperature Range: -30 to 100°C (-22 to 212°F)
• Protection Class: IP20
• Housing Material: PA 6.6
• Weight: ~60 grams (2.12 oz)
• Mounting: Din Rail
• Connections: Screw Terminal (Max. 1.5mm2, Wire-end Sleeves)

Feature

• Non-contact measurement for safe and reliable operation
• High accuracy and repeatability for precise vibration monitoring
• Wide measuring range to accommodate a variety of applications
• Rugged construction for use in harsh industrial environments
• Easy installation and maintenance
