Bently Nevada 330780-91-05 Proximitor Sensor

Description

The BENTLY NEVADA 330780-91-05 is a high-precision proximitor sensor designed for non-contact measurement of vibration and displacement in industrial machinery. It is part of the 3300 XL series and is optimized for extended linear range and high-resolution signal processing.

Features

• High Accuracy: Provides precise measurements with an output of 3.94 V/mm (100 mV/mil).
• Wide Frequency Range: Suitable for various vibration monitoring needs with a frequency range of 0 to 8 kHz.
• Flexible Mounting Options: Can be mounted on DIN rail or panel for easy installation.
• Enhanced Performance: Offers superior accuracy and a wider linear range compared to standard sensors.
• Robust Design: Excellent resistance to radio frequency interference (RFI) for reliable operation.

Technical Specifications

• Sensor Type: Proximitor (Eddy-current)
• Target Diameter: 11 mm
• Output: 3.94 V/mm (100 mV/mil)
• Frequency Range: 0 to 8 kHz
• Mounting Options: DIN rail or panel mount
• Operating Temperature: -35°C to +82°C
