Allen Bradley 1606-XLS480E-3 480W DC Power Supply Module Brand New

Overview
The AB 1606-XLS480E-3 is a high-performance 480W DC power supply from Allen-Bradley. It is designed for use in a wide variety of industrial applications, including machine control, automation, and process control. The power supply features a 24V DC output with an output current of 20A continuous and 30A for 4 seconds. It has a three-phase input that accepts 380-480V AC at 50-60Hz. The power supply is DIN-rail mountable for easy installation.


• Output voltage: 24V DC
• Output current: 20A continuous, 30A for 4 seconds
• Output power: 480W continuous, 720W for 4 seconds
• Output ripple: < 100mVpp, 20Hz to 20MHz
• Input voltage: 380-480V AC, ±15%
• Line frequency: 50-60Hz, ±6%
• AC Input current: 0.79 / 0.65A at 3x400 / 480Vac
• Power factor: 0.94 / 0.95 at 3x400 / 480Vac
• AC Inrush current: 3A peak
• Efficiency: 95.0 / 94.8% at 3x400 / 480Vac
• Losses: 25.3 / 26.4W at 3x400 / 480Vac
• Temperature range: -25°C to +70°C operational, derating 12W/°C above +60°C
• Hold-up time: 22 / 22ms at 3x400 / 480Vac
• Dimensions: 65x124x127mm (WxHxD)

Features:

• High efficiency: Up to 95%
• Small size: 65x124x127mm (WxHxD)
• Short-term peak power capability: 150%
• Built-in large sized output capacitors
• High immunity to transients and power surges
• Low electromagnetic emission
• Integrated output power manager
• Wide range input voltage design
• Virtually no input inrush current
• Dry DC-ok contact
• Green DC-ok LED
• Red overload LED
• Unique quick-connect spring-clamp terminals
• Large international approval package
•

NEW AND ORIGINAL ITEMS IN STOCK WITH ONE YEAR WARRANTY
