ABB DC532 1SAP240100R0001 Digital Input/Output Module In Stock

General Information

Extended Product Type: DC532
Product ID: 1SAP240100R0001
ABB Type Designation: DC532
EAN: 4016779649162
Catalog Description: Digital input/output module. 16 DI: 24VDC. 16 configurable DI/DO: 24VDC 0.5A (DC532)
Long Description: DC532: S500 Digital input/output module. 16 DI: 24VDC. 16 configurable DI/DO: 24VDC 0.5A. 1-wire.

Ordering

• CN8: 85389091
• Invoice Description: Digital input/output module. 16 DI: 24VDC. 16 configurable DI/DO: 24VDC 0.5A (DC532)
• Made To Order: No
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit of Measure: piece

Dimensions

• Product Net Weight: 0.114 kg
• Product Net Depth / Length: 62 mm
• Product Net Height: 76 mm
• Product Net Width: 67.5 mm
• Gross Weight: 0.138 kg
• Package Level 1 Depth / Length: 84 mm
• Package Level 1 Height: 72 mm
• Package Level 1 Width: 71 mm
• Package Level 1 Units: 1 carton

Technical

• Function: 16 DI: 24VDC. 16 configurable DI/DO: 24VDC 0.5A
• Number of Digital Inputs: 16
• Number of Digital Configurable I/Os: 16
• Input Voltage Type: DC
• Input Current: 5 mA
• Maximum Input Voltage: 0 … 30 V
• Delay Time (τ): Signal Exchange 0.1 … 32 ms
• Output: Transistor
• Output Voltage Type: DC
• Output Current: 0.5 A
• Output Voltage Maximum: 20.4 … 28.8 V
• Degree of Protection: IP20
• Supply Voltage: 20.4 … 28.8 V DC

Additional Information

• Product Main Type: DC532
• Product Name: Distributed Automation I/Os

Classifications

• eClass: 27-24-22-04
• ETIM 8: EC001419 - PLC digital I/O-module
• UNSPSC: 32151705

Environmental

• SCIP: 37dc1f5d-8a13-4e11-9ee5-efcbc63dab42 Germany (DE)
• WEEE B2C / B2B: Business To Business
• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
