ABB DC532 1SAP240100R0001 Digital Input/Output Module

Product Overview:

• Global Commercial Alias: DC532
• Product ID: 3ABD10058714
• ABB Type Designation: DC532
• Catalog Description: DC532
• Long Description: The DC532 is an S500 digital input/output module. It features:
  • 16 digital inputs (DI) at 24VDC
  • 16 configurable digital inputs/outputs (DI/DO) at 24VDC, with a maximum current of 0.5A
  • 1-wire connectivity

Ordering Information:

• CN8 Code: 85044040
• Invoice Description: DC532
• Made To Order: No
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit of Measure: piece

Dimensions:

• Net Weight: 0.114 kg
• Depth / Length: 62 mm
• Height: 76 mm
• Width: 67.5 mm
• Gross Weight: 0.138 kg

Packaging:

• Package Level 1 Depth / Length: 84 mm
• Package Level 1 Height: 72 mm
• Package Level 1 Width: 71 mm
• Package Level 1 Units: 1 carton

Technical Details:

• Degree of Protection: IP20

Additional Information:

• Product Name: PLC-AC500

Classifications:

• UNSPSC Code: 32151700

Environmental Considerations:

• WEEE Category: Product Not in WEEE Scope
