ABB 5SHX2645L0004 3BHL000389R0104 IGCT Module In Stock

Description of ABB 5SHX2645L0004 3BHL000389R0104

The ABB 5SHX2645L0004 3BHL000389R0104 is a high-performance IGBT (Insulated Gate Bipolar Transistor) module. It is designed for industrial environments requiring efficient energy conversion and robust operation. With high voltage and current capabilities, it is ideal for applications such as motor drives, renewable energy systems, and HVDC power transmission.

Features of ABB 5SHX 2645L0004 3BHL000389R0104

• High efficiency: Reduces energy losses during switching operations.
• Press-pack design: Ensures uniform pressure distribution and easy heat dissipation.
• Compact size: Optimizes space usage in converters and cabinets.
• Thermal robustness: Performs reliably across a wide temperature range.
• High isolation voltage: Guarantees operational safety in high-voltage environments.

Technical Specifications of ABB 5SHX 2645L0004 3BHL000389R0104

• Collector-Emitter Voltage (V_CES): 4500 V
• Collector Current (I_C): 1200 A
• Gate Voltage (V_GE): ±20 V
• Switching Frequency: Up to 1 kHz
• Operating Temperature Range: -40°C to +150°C
• Isolation Voltage: 6000 V RMS
• Package Type: Press-pack
• Weight: Approximately 2.5 kg

Applications of ABB 5SHX 2645L0004 3BHL000389R0104

• Industrial motor drives for heavy machinery
• Renewable energy systems: Solar and wind power inverters
• HVDC power transmission systems
• Railway traction systems
• High-power converters for automation and industrial control
