ABB 3BHE036348R0103 XZC826A103 PCB Board

Overview
The ABB 3BHE036348R0103 XZC826A103 is a compact and high-performance power supply module designed for reliable and efficient operation in industrial automation applications. It provides a stable 24V DC output power supply, capable of handling a wide range of input voltage ranges and frequencies. The module's robust design and advanced features make it well-suited for demanding industrial environments, ensuring continuous and reliable power supply for critical industrial devices.

Technical Specifications

• Type: Single-channel, 24V DC
• Input voltage: 85-264 VAC
• Input frequency: 47-63 Hz
• Output voltage: 24V DC
• Output current: 35A
• Efficiency: Up to 90%
• Protection: Overload, overvoltage, short circuit
• Dimensions: 115 x 55 x 30 mm
• Weight: 0.5 kg
• Operating temperature range: -25 to +70 °C
• Storage temperature range: -40 to +85 °C
• Humidity range: 5 to 95% RH (non-condensing)

Features:

• Provides a constant 24V DC output voltage for consistent power delivery
• Wide input voltage range (85-264 VAC) and frequency range (47-63 Hz) for compatibility with various power sources
• High efficiency up to 90% for minimizing power consumption and heat generation
• Overload protection safeguards the module and connected devices from excessive current draw
• Overvoltage protection prevents damage from sudden voltage spikes or surges
• Short circuit protection ensures system safety in case of accidental short circuits
• Small footprint for space-constrained applications
• Conforms to IEC 60068-2-30 for vibration and shock resistance
