3BUR001455R1 ABB DO814 Digital Output Module

Features and Benefits

• Channels: 16 channels for 24V DC current sinking outputs
• Isolated Groups: 2 isolated groups of 8 channels with process voltage supervision
• Output Status Indicators: OSP sets outputs to a predetermined state upon error detection
• Protection:
  • Short-circuit protection to ground and 30V
  • Over-voltage and over-temperature protection

General Information

• Article Number: 3BUR001455R1
• Type: Digital Output
• Signal Specification: 24V DC (12-32V DC), 0.5A
• Number of Channels: 16
• Signal Type: Current sinking, current limiting
• HART: No
• SOE: No
• Redundancy: No
• High Integrity: No
• Intrinsic Safety: No
• Mechanics: S800

Detailed Data

• Isolation: Groupwise isolated from ground
• Current Limiting: Short circuit-proof current-limited output
• Maximum Field Cable Length: 600 meters (656 yards)
• Rated Insulation Voltage: 50V
• Dielectric Test Voltage: 500V AC
• Power Dissipation: Typ. 2.1W
• Current Consumption +5V Modulebus: 80mA

Diagnostics

• Front LEDs: F(ault), R(un), W(arning), O(SP), Channel 1-16 Status
• Supervision: Process voltage (1 per group)
• Status Indication of Supervision: Module Error, Module Warning, Channel error

Environment and Certification

• CE Mark: Yes
• Electrical Safety: EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201
• Hazardous Location:
  • C1 Div 2 cULus
  • C1 Zone 2 cULus
  • ATEX Zone 2
• Marine Certification: ABS, BV, DNV, LR
• Temperature (Operating): 0 to +55 °C (+32 to +131 °F) (approvals are issued for +5 to +55 °C)
• Temperature (Storage): -40 to +70 °C (-40 to +158 °F)
• Pollution Degree: Degree 2, IEC 60664-1
• Corrosion Protection: ISA-S71.04: G3
• Relative Humidity: 5 to 95%, non-condensing
• Max Ambient Temperature:
  • 55 °C (131 °F) for vertical mounting in compact MTU
  • 40 °C (104 °F) for other configurations
• Protection Class: IP20 according to IEC 60529
• Mechanical Operating Conditions: IEC/EN 61131-2
• EMC: EN 61000-6-4, EN 61000-6-2
• Overvoltage Categories: IEC/EN 60664-1, EN 50178
• Equipment Class: Class I according to IEC 61140 (earth protected)
• RoHS Compliance: DIRECTIVE/2011/65/EN (EN 50581:2012)
• WEEE Compliance: DIRECTIVE/2012/19/EU

Compatibility

• Use with MTU: TU810, TU812, TU814, TU830, TU833, or TU838
• Keying Code: BE

Dimensions

• Width: 45mm (1.77”)
• Depth: 102mm (4.01”), 111mm (4.37”) including connector
• Height: 119mm (4.7”)
• Weight: 0.18kg (0.4 lbs.)
