1715-OB8DE | Allen Bradley | 8 Channel Digital Output Module

Allen Bradley 1715-OB8DE Overview

The Allen Bradley 1715-OB8DE is an 8-channel digital output module designed for CompactLogix controllers. This module controls external devices such as solenoids, motors, and lights. It offers features like short-circuit protection, overload protection, and status indication, making it suitable for industrial automation applications.

Technical Specifications

• Manufacturer: Allen Bradley

• Product No.: 1715-OB8DE

• Product Type: 8 Channel Digital Output Module

• Fuses: 50 mA per channel

• Screw Torque: 0.5 N•m (0.37 lb•ft)

• Screwdriver Width: Flathead 0.4 x 2.0 mm (0.0156 x 0.0781 in.)

• Backplane Current: 165 mA @ 18…32V DC

• Field Voltage Slew Rate (max): 150 V/s

• De-energized Output Voltage Slew Rate (max): 12 V/ms

• Energized Output Current Slew Rate (max): 0.9 A/ms

• Power Dissipation:

  • System: 3.0 W max
  • Field Loop: 0.17 W per field loop

• Isolation Voltage: 50V (continuous), basic insulation type, I/O ports to backplane

  • No Isolation Between Individual I/O Ports
  • Type Tested at: 500V AC for 60 s

• Dimensions: 11.8 cm x 4.2 cm x 16.6 cm (D x W x H)

• Weight: 0.29 Kg
